Dinosaur classification - Evolutionary Tree of Dinosaurs

Dinosaurs evolved during the Mesozoic Era from about 251 million years ago (Ma) to 65.5 million years ago. The rise of the dinosaurs started in a world with little oxygen after the Permian-Triassic mass extinction which killed 90% of ocean dwellers and 70% of land plants and animals. This was Earth's worst mass extinction — atmospheric oxygen levels dropped from 30% to 12%. Modern birds, which are descendants of the dinosaurs, still show the adaptation to survive in low oxygen levels as they fly at heights of up to 10,000 meters (33,000 feet) in their migrations across the Himalayas.[1]  All non-avian dinosaurs became extinct 65.5 million years ago as a result of climatic changes caused by the Deccan Traps volcanic eruptions in India and a large meteorite impact in Mexico's Yucatan peninsula.

Chicken
Birds are the modern
descendants of dinosaurs

The Mesozoic Era is divided into three periods. During the Triassic Period (251 to 199.6 Ma) the land was populated by reptiles, and one subclass of them, the Archosauria, evolved to give rise to crocodilians, flying reptiles, dinosaurs and birds. The Triassic was also the time when the first mammals, such as Morganucodon appeared. The transition between the Triassic and the Jurassic Period is associated with a large magma flow in the Central Atlantic province that occurred during the breakup of Pangaea and the formation of the Atlantic Ocean. The end of the Triassic was marked by an extinction event that killed more than 20% of all marine families. The Jurassic Period (199.6 to 145.5 Ma) was populated by dinosaurs that were giant herbivores and vicious carnivores. Flying reptiles (Pterosaurs) appeared and the first birds like Arcaeopteryx also appeared. The Cretaceous Period (145.5 to 65.5 Ma) was marked by active crust plate movements. Africa and India separated from Antarctica, and South America separated from Africa. During this period, flowering plants and social insects like bees and ants appeared. The first birds with beaks without teeth also appeared during the Cretaceous. Large herbivores and Tyrannosaurus rex thrived during the late Cretaceous until an asteroid impact caused the extinction of the dinosaurs and the transition to the Cenozoic Era, which is our current era. Within five million years after the extinction of the dinosaurs, mammals prospered and diversified, and 70% of new bird lineages evolved.

Dinosaurs are classified into two primary branches, Saurischia and Ornithischia, based on the anatomy of their pelvic structure.

Saurischians ("lizard-hipped", from the Greek sauros meaning "lizard" and ischion meaning "hip joint") have a hip structure with a pubis bone directed forward. Birds evolved from Saurischian dinosaurs.

Ornithischians ("bird-hipped", from the Greek ornitheios meaning "of a bird" and ischion meaning "hip joint") had a pelvis that superficially resembled a bird's pelvis with the pubis bone pointing to the rear. Ornithischia includes a variety of species which were primarily herbivores. The backwards pointing pubic bones of ornithischians resemble those of birds, but this similarity is an evolutionary convergence that does not correspond to a close relationship. Birds belong among saurischian dinosaurs, not among the ornithischians. The second trait that distinguishes ornithischians is a special bone in the lower jaw, called the predentary which was an adaptation for clipping off plant material and enabled a vegetarian lifestyle.

Saurischian pelvis
Saurischian pelvis
Ornithischian pelvis
Ornithischian pelvis


Saurischia
"lizard-hipped dinosaurs"

The saurischians form two major groups. The Theropoda were bipedal carnivores (meat eaters that walked on two legs), and the Sauropoda were large quadruped herbivores (plant eaters that walked on four legs).

Allosaurus
Allosaurus - A therapod slightly smaller than Tyrannosaurus rex

Therapoda
The theropods (meaning "beast-footed") dinosaurs were a diverse group of bipedal dinosaurs that could be as small as a chicken or as large as the enormous Tyrannosaurus. Theropoda were primarily carnivorous, but some theropod groups evolved to also eat plant seeds, fruits and insects. Dinosaurs shed their teeth throughout their life, like modern sharks. Adult velociraptors had a long tail and measured up to 6.8 feet (2 meters) from the head to the tip of the tail. These dinosaurs were covered with feathers and had an enlarged sickle-shaped claw on each hind foot. DNA studies have conclusively shown that birds are actually the descendants of small non-flying theropods.

Tyrannosaurus rex skull
Tyrannosaurus rex tooth
A human hand compared to a tooth of Tyrannosaurus rex

Tyrannosaurus rex was one of the largest carnivorous therapods of the Cretaceous period. A specimen could measure up to 12.3 meters (40 ft) in length, have a height of up to 4 meters (13 ft) at the hips, and weigh up to 6.8 metric tons. Tyrannosaurus rex is one of the best-known dinosaurs because its enormous size and ferocity have been the topic of movies such as Jurassic Park.

Spinosaurus
Spinosaurus had semiaquatic adaptations

Dinosaurs lived primarily on land, but Spinosaurus aegyptiacus, a giant predatory dinosaur, had adaptations for a semiaquatic lifestyle. Unlike terrestrial theropods, the pelvic girdle of Spinosaurus was downsized, the hindlimbs were short, and all of the limb bones were solid without an open medullary cavity, for buoyancy control in water. Its short, robust femur with hypertrophied flexor attachment and the low, flat-bottomed pedal claws are consistent with aquatic foot-propelled locomotion.[2]

Sauropods
Sauropods had very long necks and tails

Sauropodomorpha
The Sauropodomorpha (meaning "lizard-footed forms") were herbivorous, saurischian dinosaurs that include the sauropods and their ancestral relatives. These dinosaurs were large herbivores with very long necks, long tails, small heads, and thick, pillar-like legs reminiscent of the limbs of elephants. The nostrils of these animals were located high up on the skulls, rather than being located at the end of the snout like in many other terrestrial vertebrates. Some of the sauropods had a rudimentary body armor consisting of skin calcifications called osteoderms. Apatosaurus, a sauropod previously known as Brontosaurus, lived from about 154 to 150 million years ago, during the Jurassic Period.

Ornithischia
"bird-hipped dinosaurs"

Ornithischia were beaked, herbivorous dinosaurs that sometimes lived in herds and were frequent prey animals for the theropods. The predentory bone at the tip of their lower jaw helped to form a cropping beak that was used for slicing off plant stems and this allowed the teeth in the back of their jaws to become specialized for grinding and chewing. The Ornithischia family tree is divided into the Thyreophora ("shield bearers" or "armored dinosaurs") that include the branches Stegosauria and Ankylosauria, and the Neornithischia ("new ornithischians") that include the branches Ornithopoda, Ceratopsia and Pachycephalosauria.

Thyreophora "armored dinosaurs"

Stegosaurus
Stegosaurus

Stegosauria
Stegosaurs ("covered lizards") lived during the Jurassic and early Cretaceous period mostly in the Northern Hemisphere, predominantly in what is now North America, Europe and China. The Stegosauria were herbivorous ornithischian dinosaurs that had complex arrays of spikes and plates running along their backs, hips and tails. These bony plates were not part of the skeleton; they were skin ossifications called osteoderms. The spikes in the tail consisted of an arrangement of four to ten spikes that were used for defense.

Stegosaurs walked on all four legs, although their front legs were substantially shorter than their back legs. The head was very small compared to the rest of the body, and it was carried close to the ground. Stegosaurs had a very narrow beak and leaf-shaped teeth. Stegosaurians became extinct during the first half of the Cretaceous period.

ankylosaurus
Ankylosaurs were heavily armored

Ankylosauria
Ankylosauria ("stiff lizards") is a group of herbivorous ornithischian dinosaurs that includes the great majority of dinosaurs with armor in the form of bony osteoderms. Ankylosaurs were quadrupeds, with bulky fat bodies and short, powerful limbs. Their skulls were wedge-shaped with angular edges, and their teeth were small and leaf-shaped. In some but not all Ankylosaurs, the end of the tail was modified to form a tail club with huge osteoderms that was used for defense.

Neornithischia "new ornithischians"

charonosaurus
Charonosaurus - Example of Ornithopoda

Ornithopoda
The ornithopoda ("bird legged") include the duck billed hadrosaurs and iguanodons which evolved complex dentations for shearing and grinding plants. Iguanodons were a very populous group of ornithopods with many species known from the Middle Jurassic to the Early Cretaceous. Iguanodons had a characteristic spiky thumb whereas hadrosaurs had a hand that was encased in a mitten of skin. Some hadrosaurs had elaborate crests on the top of their skulls, while others had flat heads.

hadrosaur eggs
Fossilized hadrosaur eggs
Xiaxia Basin, Henan Province, China
Cretaceous Period, ~100 Ma

Hadrosaurids, or duck-billed dinosaurs, were common herbivores in the Cretaceous Period of what is now Asia, Europe and North America. Hadrosaurids are descendants of the earlier iguanodontian dinosaurs and had a similar body layout.

Triceratops
Ceratopsia had skulls with bony frills

Ceratopsia
the ceratopsians ("horn faced") include the well-known Triceratops. These plant-eating dinosaurs walked on four legs and had relatively short tails compared to other dinosaurs. The frill at the back of the head was made up of bones from the back of the skull that became very elongated and protected the neck. Many of the ceratopsians also had horns over their eyes and their beak resembled a parrot's beak, but the jaw still had elaborate banks of teeth for shearing and crushing plant material. The earlier forms of ceratopsians did not have quite as elaborate frills and horns as the later forms.

Ceratopsids
Ceratopsids had a wide variety of horns, knobs and frills.

Ceratopsids had elaborate horns and frills. These characteristics are the principal means for recognizing various species. The large horns and frills may have been used as a defense against the large carnivorous predators like T. rex, but they may have also served as displays for attracting mates or to combat competing suitors.

Pachycephalosaur
Pachycephalosaurs had extremely thick skulls

Pachycephalosauria
Pachycephalosauria ("thick headed lizards") is a clade of ornithischian dinosaurs that lived during the Late Cretaceous Period, in what is now North America and Asia. These dinosaurs had a high domed skull, but their brains were not very big. Most of the volume of the skull was solid bone. It is thought that these dinosaurs used their heads as battering rams against other members of the same species when competing for mates or defending territory. Examination of the skull of a specimen of Pachycephalosaurus wyomingensis found cranial lesions that are consistent with agonistic behavior in pachycephalosaurs.[3]

Dinosaur Names
Dinosaurs and other organisms, whether living or extinct, are named according to a set of rules established by Carl Linnaeus, an 18th century Swedish scientist. The names consist of two parts representing the genus and species. These binomial names are printed in italics and the first part is capitalized. Thus, Tyrannosaurus rex is the name of a carnivorous therapod that lived during the Cretaceous Period. The binomial names usually describe notable features of the organism in Latin, although some of the name roots may be Greek. Tyrannosaurus means tyrant lizard and rex means king. Triceratops means three horned face. The following table lists some of the most common roots used in dinosaur names.

Root Meaning
acantho spiny
acro high
aeto eagle
allo other
alti high
ambi both or two
amphi both or two
an not or without
anato duck
anchi near
ankylo fused, stiff
anser goose
antho flower
anuro no tail
apato deceptive
apsid, apsis arch
archaeo ancient
archo leader
arthro joint
avi, avis bird
bactro baton or club
baga little
baro, bary heavy
bellu beautiful
brachio arm
brachy short
bronto thunder
calamo reed
camara chamber
campto flexible
campylo bent
carchar jagged
cardio heart
carno flesh
caud, caudia tail
centro point, center
cephalo head
cera, ceras horn
cerno divide or sever
cero horn
chasmo chasm or large fissure
chiro, cheirus hand
chondro cartilage
cion column or pillar
clao break or crush
cneme lower leg or shin bone
coeli, coelo opening or cavity
compso elegant
coryth helmet
costa rib
cryo cold
crypto hidden
cyon dog
dactly finger
deino fearsome or terrible
derm skin
di two
dino fearsome or terrible
diplo double or in pairs
docus beam, bar or shaft
don, dont tooth
draco dragon
dromeus, dromeo runner
drypto wounding
echino spiny
elasmo metal plated or elastic, like thin, beaten metal
elmi foot
eo dawn
equus horse
eu good or well
eury wide
felis cat
giga savage giant
gnathus jaw
hadro large
hetero mixed or different
hippos horse
hydro water
hypacro top
hypselo, hypsi high
ichthyo fish
iguano iguana
kentro sharp point or spur
krito chosen or separated
lana woolly
lepido scaly, with scales
lepto thin or slender
lestes robber
lio smooth
lite, lithos stone
lopho, lophos crest or tuft
lyco wolf
lystro shovel
maia good mother
macro long or large
megal great
micro small
mio less
mono single or alone
masso long or bulky
mega huge
merus part or portion
metro measure
micro tiny
mimus mimic
morph shape
nano dwarf or very small
neo new
neustes swimmer
nodo knotted or lumpy
noto node or nodulus
notos south
nycho, nychus clawed
odon, odont tooth
oid, oides like
oligo few or little
onyx claw or talon
opistho at the back or behind
ops eye or face
opsis face
ornis, ornitho bird
oro, oros, oreios mountain
ortho straight
ovo, ovi egg
pachy thick
para beside
patri father
pedi foot
pelon mud or clay
peloro monstrous
penta five
phalanges fingers or toes
phyllo leaf
physis form
placo broad or flat
plateo flat
plesio near
pleuro side or rib
plio more
pogon beard
poly many or much
pod, pos foot or to put
preno sloping
prio saw
pro before
protero earlier or former
proto first or earliest
pseudo false
psittaco parrot
ptero, pteron feather or wing
pteryx wing or fin
pyro fire
quadr four
raptor robber or plunderer
rex king
rhinus, rhino nose or snout
rhomale robust or strong
saetum bristle
salto leaping
sarco flesh
saur, saurus,
sauro, sauros
lizard (or reptile, in general)
scapho canoe
scelida hind leg
segno slow
seismo earthquake
Sino Chinese
smilo knife
spino thorn or backbone
spondyl vertebrae
stego roof or cover
steno narrow, close or slender
strepto reversed
struthio ostrich
styraco spiked
suchus crocodile
tetra four
thallasso sea
thero, therium beast
titano titanic
tops face
tri three
troo wound
tyranno tyrant
ultra extreme
uro, urus tail
veloci speedy
venator hunter
vulcano volcano
zo, zoa, zoon animal(s) or life
zygo joined

  Learn about the Geologic and Biological Timeline of the Earth

Where to dig for Dinosaur Fossils

References:
  1. List of birds by flight heights
  2. Nizar Ibrahim, et al., Semiaquatic adaptations in a giant predatory dinosaur, Science 26 September 2014: Vol. 345 no. 6204 pp. 1613-1616, DOI: 10.1126/science.1258750
  3. Joseph E. Peterson, Christopher P. Vittore, Cranial Pathologies in a Specimen of Pachycephalosaurus, PLoS One, 2012; 7(4): e36227. Published online Apr 30, 2012. doi: 10.1371/journal.pone.0036227, PMCID: PMC3340332
